產品
我們的產品和解決方案可為各種裝置提供穩定的時脈信號、實現5G與5G Advanced網絡速度、提供自動駕駛車輛精確定位與滿足云端計算的同步要求。
晶體振蕩器
9C 系列 (2016 MHz)
Features :
·Ultra small ceramic package 2.0x1.6x0.74mm Max.
·High reliability with Seam welding
·CMOS output ，32.768khz， 1.5Mhz~125Mhz
·Wide operating voltage range 1.6 to 3.63v ,5.0v
·Low current consumption
Applications :
·Consumer/ Networking / Industrial / Base station
2C 系列 (2520 MHz)
Features :
·Ultra small ceramic package 2.5x2.0x0.8mm Max.
·High reliability with Seam welding
·CMOS output ，32.768khz， 1.5Mhz~125Mhz
·Wide operating voltage range 1.6 to 3.63v ,5.0v
·Low current consumption
Applications :
·Consumer/ Networking / Industrial / Base station
3C 系列 (3225 MHz)
Features :
·Ultra small ceramic package 3.2x2.5x1.0mm Max.
·High reliability with Seam welding
·CMOS output ，32.768khz， 1.5Mhz~125Mhz
·Wide operating voltage range 1.6 to 3.63v ,5.0v
·Low current consumption
Applications :
·Consumer/ Networking / Industrial / Base station
5C 系列 (5032 MHz)
Features :
·Ultra small ceramic package 5.0x3.2x1.2mm Max.
·High reliability with Seam welding
·CMOS output ，32.768khz， 1.5Mhz~125Mhz
·Wide operating voltage range 1.6 to 3.63v ,5.0v
·Low current consumption
Applications :
·Consumer/ Networking / Industrial / Base station
7C 系列 (7050 MHz)
Features :
·Ultra small ceramic package 7.0x5.0×1.3mm Max.
·High reliability with Seam welding
·CMOS output ，32.768khz， 1.5Mhz~125Mhz
·Wide operating voltage range 1.6 to 3.63v ,5.0v
·Low current consumption
Applications :
·Consumer/ Networking / Industrial / Base station
